10 Layer PCB Fabrication-PCBLike.com

Product Detail:

10-layer PCBs are becoming more and more popular in the satellite, GPS, and memory module industries. Hecheng Fast Electronic Technology has provided services from prototype 10-layer PCB manufacturing to mass production for more than 9 years.

10-layer board manufacturing process:

Shear material to size/baking material—> Inner layer drilling—> Inner layer pattern transfer—> Inner layer circuit inspection—> Etching/stripping—> Etching inspection—> Browning- –> Preparation of prepreg—> Laminate—> Cutting of copper foil—> Positioning—> Laminating—> Target hole—> Drilling—> Glue removal Slag—> Immersed Copper—> Graphic Transfer—> Line Inspection—> Copper and Tin Plating—> Removal Film Etching—> Removing Tin—> Etching Inspection—> Medium Inspection Test—> Solder Mask—> Solder Mask Inspection—> Text—> Baking Plate—> Spray Tin, Immersion Gold, Immersion Tin—> Shape—> V Cut- –> Finished product test—> Anti-oxidation—> Final inspection—> Finished product extraction—> Packaging

10-layer board lead time:

The price generally depends on process requirements, quantity, board size, etc. Customers can send us a quotation in Gerber files. Generally, the delivery time of 10-layer boards in a factory is about 10-12 days. In order to meet customer needs, PCBLike accepts urgent orders, which can be completed within one week as soon as possible.
